How to Achieve a Mirror Finish on Stainless Steel?

On stainless steel, a mirror finish is a highly-polished commercial finish characterised by a bright, shiny and reflective surface. You'll most commonly find it in aesthetic pieces, such as public architecture, tapes and furniture. Not only is a mirror finish visually appealing, but the gradual removal of scratches on the surface through mechanical polishing processes also reduces troughs or grooves in the material that harbour contaminants, such as dirt or bacteria, in day-to-day use. Have a look out for objects around you - you'll notice things like your bathroom taps, perhaps a modern coffee table or even your kitchen pots are likely to be finished to a mirror polish.

What are the main benefits of a mirror finish?

Not only is it aesthetically pleasing, but it's also far less susceptible to contamination than rougher surface finishes. You achieve this smooth surface by working through grit grades in mechanical applications to gradually remove scratches and imperfections from the metal. In more technical terms, mirror-finished steel will have a Ra reading of less than 0.2 - Ra, or roughness average, which measures microscopic peaks and troughs on the surface of the metal, the lower the number, the fewer or smaller the peaks and troughs are, meaning that your metal surface is smoother and more reflective.

What are the downsides?

It's important to remember that this isn't a desirable finish for everything - it's high-shine which means it does require constant maintenance to maintain the perfect mirror. If something such as a public bannister was imparted with a mirror finish, it'd be covered with visible unsightly finger marks within minutes. In high-traffic areas, or on pieces where function over form is more important, you're more likely to benefit from imparting a lower grade finish to your workpiece.

Step by step guide

For stainless steel applications, choosing a TIG over a MIG weld is invariably the better option. MIG welds are great for thick, heavy duty applications, whilst TIG welds are the better choice for thinner pieces of metal. TIG welds also are less likely to leave contaminants and imperfections (such as spatter) on the metal, meaning less rework is needed following the welding process to get to your final desired finish.

Step 1: Remove

Use a flap disc in grit 80 to remove TIG weld material from your piece. The flap discs have lower disc wear for a longer grinding time, without loss of cut throughout disc life.

Step 2: Blend

Use a Rapid Blend disc to blend out scratches from your material removal step. The discs are made of nylon fibres and lay the foundations for a bright finish to your stainless steel piece. Reduce the speed to 5 ' 6,000 RPM and use slow, even strokes at a 10 - 15 degree angle to impart a consistent matt satin finish.

Step 3: Refine

Use a disc in 2SF to refine your satin finish and keep the grinder speed low. The fine grade silicon carbide abrasive and nylon fibres in grade 2SF (soft & semi-conformable), or in grade 3SF(slightly harder & more durable) impart a finer / brighter finish.

By the end of this process, you should have a smooth, bright satin finish, taking the time to remove imperfections at this stage in mirror finishing will make your final polishing step quicker and more effective.

Step 4: Polish

So, you have refined your workpiece and removed all scratches and imperfections, you are now ready to polish your stainless steel workpiece. Reduce the speed of your grinder to 2-3000 RPM for use with a felt wool polishing pad. Using a white polishing compound block, apply some compound to your felt disc by offering the bar to the disc whilst the machine is running. If the workpiece is still hot from the previous processes you can even apply some compound directly to the surface, the more the better!

Now, applying minimum pressure and just using the weight of the machine to guide you, slowly pass the grinder in regular strokes up and down your surface. This process takes time, and you will need to stop at regular intervals to re-apply the compound and check the surface finish, some imperfections you have missed from your refining step might now become apparent, and it may be necessary to go back to step 3 to re-work your workpiece if an extremely high standard is required.
